20:1 Chamber Air Purge & NFPA 99 Compliance Kit

Make Any Hyperbaric Chamber NFPA 99 Compliant

The 20:1 Chamber Air Purge Kit is Prestige Hyperbaric's dedicated safety-and-compliance upgrade for any brand of hyperbaric chamber. It delivers a high-volume stream of clean room air alongside your existing oxygen concentrator output — pushing the ambient chamber air-to-concentrated-O₂ ratio to 20:1 and keeping the inside of the chamber safely below the 23.5% FiO₂ threshold defined in NFPA 99, Health Care Facilities Code.

Standard chambers run about a 9:1 dilution ratio. That's fine for home use, but as soon as an oxygen concentrator is running the chamber atmosphere begins climbing toward oxygen-enriched levels. NFPA 99 defines an oxygen-enriched atmosphere as anything above 23.5% O₂, and once you cross that line the whole environment is treated as a fire-risk space. Our 20:1 kit more than doubles the room-air side of the equation so you stay comfortably under the code threshold — without ever cutting your therapy time or your working pressure.

Why buy the Air Purge Kit

• NFPA 99 compliant — with add-on installed. Keeps the chamber atmosphere below 23.5% O₂, the fire-safety threshold referenced by NFPA 99 (Health Care Facilities Code).
• 20:1 dilution ratio. Room air to concentrated O₂ pushed from the standard 9:1 to a code-safe 20:1. Run two 10 LPM concentrators (20 LPM total) and the ratio moves to 10:1 — still well under the standard 4.5:1 ratio of a stock 20 LPM system.
• CO₂ & waste-gas purge. Higher air throughput actively flushes carbon dioxide, VOCs, and other exhaled waste out of the chamber — cleaner atmosphere for every session.
• Faster pressurization. The extra clean-air flow gets your chamber to therapeutic pressure faster than the stock compressor alone.
• Universal fit. Adapts to any hyperbaric chamber — Prestige Hyperbaric, Oxycell, OxyRevo, Oxygen Health Systems, Airvida, Macy-Pan, Olive, Summit to Sea, Vitaeris, and virtually every other brand on the market.
• Pro install support included. Every kit ships with tailored install guidance from our team — we adapt the fittings, hose runs, and control setup to your specific chamber.

How the 20:1 dilution works

Every hyperbaric chamber is a mix of two air streams: compressed room air from the air compressor and concentrated oxygen from one or more oxygen concentrators. The ratio between the two determines the FiO₂ inside the chamber.

• Standard 10 LPM system, no upgrade: ~9:1 ratio — chamber climbs toward oxygen-enriched territory.
• Standard 20 LPM system, no upgrade: ~4.5:1 ratio — chamber runs even richer in oxygen.
• 10 LPM + 20:1 Air Purge Kit: 20:1 ratio — chamber stays cleanly below 23.5% O₂.
• 20 LPM + 20:1 Air Purge Kit: 10:1 ratio — code-safe headroom even at maximum therapeutic O₂ flow.

What's in the kit

• High-flow hyperbaric-style air purge pump
• Precision inline HEPA filter (99.97% at 0.3 micron)
• Chamber-side quick-connect fittings and pressure gauge
• Braided reinforced supply hose sized for your chamber
• Control panel with adjustable purge rate
• Written install guide plus one-on-one setup call with our engineering team

Fits every major chamber brand

The 20:1 Chamber Air Purge Kit is a universal safety and compliance upgrade. We regularly install it into:

• Prestige Hyperbaric (Vessel of Power, Sphere of Power, Pavilion of Power, Grand Vessel, Grand Sphere, Grand Vessel Rx, Grand Pavilion)
• Oxycell hyperbaric chambers
• OxyRevo (Apex, Explorer, Lamborghini, and other soft-shell and hard-shell models)
• Oxygen Health Systems (Fortius, Respiro, Elite)
• Airvida hyperbaric chambers
• Macy-Pan (all soft-shell and hard-shell models)
• Olive Hyperbaric chambers
• Summit to Sea Dive / Grand Dive
• Vitaeris 320
• Any other brand — message us and we'll confirm fitment

Power & installation notes

The high-flow pump draws more power than a standard chamber compressor and may require a dedicated 20-amp circuit depending on your room layout. During your install call we'll confirm your electrical setup and specify the plug and breaker requirements for your chamber. Installation is straightforward for anyone comfortable with hyperbaric chamber setup; our team is on the phone with you through the entire process.

Pairs with the Prestige Oxygen Analyzer

For continuous, verifiable proof that the chamber is running under 23.5% O₂, pair the 20:1 Air Purge Kit with our Oxygen Analyzer Premium ($499). Medical-grade oxygen analyzer with training — gives you a live FiO₂ readout inside the chamber so you can document compliance in real time.

Pricing & shipping

$4,000 for the complete kit. $100 flat shipping to the continental US. Ships within 5–7 business days. International shipping quoted separately — contact us for a quote.

Important — read before ordering

NFPA 99® is a registered trademark of the National Fire Protection Association. "NFPA 99 compliant" refers specifically to the <23.5% O₂ fire-safety threshold defined in the code, achieved by keeping the chamber atmosphere below that value while the 20:1 Air Purge Kit is installed and operating correctly. Full facility compliance with NFPA 99 requires review by your local Authority Having Jurisdiction (AHJ) and is the responsibility of the chamber owner and operating facility. Prestige Hyperbaric provides the hardware, installation guidance, and technical support to meet the ambient-atmosphere requirement; the customer is responsible for facility-level compliance, permitting, and inspection.

Not a medical device. Not FDA cleared. This product is a safety and ventilation upgrade for the chamber itself and does not treat any condition.
